IW28S In-Wall Subwoofer

฿48,900.00 ฿42,900.00

More than four decades of experience and insight have been applied to the design of this truly invisible subwoofer, based on high-performance 8” woofers specially developed for the M&K Sound V Series subwoofers and ingeniously adapted to meet the extreme demands of shallow, flush-mount installation while delivering the quantity and quality of deep bass that consumers and professionals expect from M&K Sound.

The specially tuned, ultra-fast, mass-loaded dual drivers employ aluminum shorting rings for minimal voice coil distortion at long excursion. Highly rigid paper pulp cones with high inner damping ensure stability at extreme levels and low resonance.
The ultra-linear solid ferrite magnet system provides effective dissipation of heat from the voice coil to prevent power compression from limiting the acoustic output of the system.

The drivers are installed in full contact with the front baffle and the rear of the box for ideal mechanical stability to minimize driver resonances that can occur due to the limited volume of an In-Wall enclosure.

The IW28s needs the VA500 Subwoofer Amplifier.

Brand

mksound

เปรียบเทียบ
เพิ่มรายการโปรด
หมวดหมู่: Inwall Series, M&K Sound, Subwoofer ป้ายกำกับ: in wall, inwall, iw28s, mk sound
Share
  • รายละเอียดเพิ่มเติม
  • บทวิจารณ์ (0)
รายละเอียดเพิ่มเติม

Specifications IW28S

Sound

Impedance 4 ohm
Bass Drivers: 2 x 8” paper pulp
Frequency Response: 28 Hz – 200 Hz, ± 3dB
Sensitivity (drive signal 100mVolt VA500 amp) 88 dB/1m

Dimensions

Grille Dimensions (HxW): 24.48 x 12.44”, 622 x 312 mm
Baffle Dimensions (HxW): 24.25 x 12.04”, 616 x 306 mm
Wall Cutout (HxW): 22.84 x10.62”, 580 x 270 mm
Mounting Depth: 3.74”, 95 mm
Weight: 24.2 lbs / 11 kg

Colors

Finish: Black satin

Downloads

Want to know more?
b

Brochure

b-02

Manual
